Avocet Affinity 3D Composite Door Hinge

-

Avocet Affinity 3D Door Hinge For Composite Doors



Replacement hinge for composite doors

Accredited by the UK Police initiative 'Secured By Design', this means they pass the PAS24 security tests.

WindowParts Ltd supply these hinges to the trade & public customers via our 3 branches and also our website.

These hinges are white with left & right handed versions available.



Active 3D adjustment with a 6mm allen key (not supplied)

±0.75mm compression adjustment ± 4mm horizontal (lateral) adjustment ± 2mm vertical adjustment.

Robust construction, endurance tested to 100,000 cycles on a 100kg sash (3 hinges).

Click here to see the Avocet Affinity 3D composite door hinge at WindowParts Ltd
